Model

(型號)

NSW-620PG

Magnification(field of view)

放大倍率(可視範圍)

6x・20x(38.3mm&11.5mm)

Eyepieces(目鏡)

Wide Field 10x (DSW10X), FN23

Objective lenses

(物鏡)

0.6x-2x

Optical Body

(光學本體)

360 degrees rotatable binocular type, 45 degrees inclined eyepiece tubes

360度雙眼可旋式目鏡, 傾角45度

Diopter adjustment

(屈光度調節)

+/-7.2D on left eyepiece tube

左目鏡調整範圍±7.2D

Interpupillary Distance

(瞳距調整範圍)

52mm-75mm

Working Distance

(工作高度)

82.5mm

Incident Illumination

光源

Built-in LED ring light with intensity control

內建LED環形光源, 亮度可調

Base Size

平台尺寸

220mm x 284mm

Overall Height(全高)

356mm

Net Weight(淨重)

4.9kg

Accessories (配件)

Rubber eyeguards, C-wrench, Dust cover

橡膠護目罩、C型板手、防塵套
